| Items | Technical Parameters |
| NO.of Drafts | ~12 |
| Design Speed | 16m/s |
| Max.Inlet Wire Diameter | Ф4.2mm |
| Inlet Wire Length | ≤1250MPa |
| Min.Outlet Wire Diameter | Ф0.9mm |
| Average Pass Reduction | 20% |
| Drum Diameter | Ф450mm |
| Drum Surface Treatment | Overall Surface Hardening |
| Drum Surface Hardness | ≥HRC55 |
| Drum Cooling Mode | Internal Slot Water Cooling |
| Motor Power | 11~22KW |
| Drive Mode | Narrow V Belt Drive |
| Speed Control | AC Frequency Converting |
| Motor Control | PLC Control |
| Take-up Spool Size | 630/760 |
